RBO-172 Rotary Rack Oven
The RBO-172 is RotoBake's largest rotary rack oven, built in New Delhi for mega-scale industrial bread plants. It holds 172 trays (13" × 18" each) across a 51,700 sq. in. baking area, baking approximately 425 loaves per 25-minute cycle, or up to 150 kg/hr of cookies. The oven operates across a ambient to 350°C temperature range and runs on diesel or gas — diesel consumption is roughly 1.5 L/hr, gas roughly 5 kg/hr. Built in food-grade steel, the RBO-172 weighs approximately 3,980 kg with overall dimensions of 117" × 88" × 98". Every RBO-172 ships with on-site installation, commissioning, and operator training included, backed by RotoBake's 10-year spare-parts guarantee. RotoBake has manufactured bakery machinery in New Delhi since 1964 and exports to bakeries across the Middle East, South Asia, and Africa.
Technical Specifications
| Tray Capacity | 172 Trays (13" × 18") |
| Baking Area | 51,700 sq.in |
| Bread Production | 425 pcs per 25 min |
| Cookie Capacity | 150 kg/hr |
| Temperature Range | Ambient – 350°C |
| Fuel Options | Diesel / Gas |
| Diesel Consumption | 1.5 L/hr |
| Gas Consumption | 5 kg/hr |
| Machine Weight | 3,980 kg |
| Overall Dimensions | 117" × 88" × 98" |
